Applications

· Used for manufacturing all kinds of precision standard tool and special tool, especially apply to cutting tool manufacturers which are expect to improve the automation of production;
· Used for regrinding various of metal cutting tool, apply to the large tool regrinding service centers or end user;

Technical Specifications

** Equivalent to the tool process capability of maximum power equipment at that level.

Machine processing can be flexibly selected SNSTC or NUM software

· SNSTC TOOL BUILDER is a self-developed, simple and efficient tool design and machine operation / programming control software, integrates automatic calibration, motion simulation and other innovative features.
· NUMROTO is a third-party integrated software package for manufacturing and regrinding various tools. It is now integrated into the GIVEAL series of grinding machines, can immediately provide accurate and efficient tool productions.
At present, SNSTC TOOL BUUDER doesn't support to manufacture gear cutter, punch and rotary burrs cutter, but the development work is being carried out closely.

Options

· Multi-functional tool support unit：

Optional multi-functional tool support unit is designed for long slender parts, overweight tools, it plays a protective and auxiliary role in grinding process.

· Online grinding wheel resharpening：

The optional on-line resharpening suite is used for removing the debris residue on the surface of the wheel, helping the diamond particles to be fully exposed, to achieve better cutting results, and to reduce improper thermal damage to the workpiece.

· Automatic grinding wheel calibration：

The probe is used for automatically measure the diameter of wheel and the installation of wheel position; Wheel measurement process can also be integrated in the programming process to achieve automatic compensation for grinding wheel Wear.

· High speed grinding spindle：

We provide high speed spindle options which the rated speed is up to 10000 r.

· Grinding wheel changer ：

Make Further enlarge the machining capability to achieve carry 4-station grinding wheel changer (maximum 5), the multi-wheel group can finished more complex precision grinding and obtain better machining quality.

· Robot Tool Loader：

Loading and unloading of the tools can be automatically carried out by the robot, which achieve unmanned operation and continuous processing. The loading capacity is determined by the pallets and the size of tools.

· Automatic fire extinguishing suite：

The fire can be automatically sensed and extinguished by high precision sensors, and without any side effects to the machine.

* We reserve the right to change the above technical parameters without prior announcement
